CS-D1600IR |
|
NEAR IR CMOS CAMERA |
| Model Name |
CS-D1600IR |
|
| Signal format |
EIA |
|
| Image Sensor |
1/4inch CMOS Sensor |
|
| Number of Pixel |
300K |
|
| Scanning System |
2 :1 Interlace |
|
| Synchronization |
Internal |
|
| Horizontal Resolution |
350 TVL |
|
| Video Out Level |
1.0Vp-p, 75 ohm |
|
| S/N ratio |
45dB or better |
|
|
Minimum Illumination |
300nm~750nm |
200000 Lux |
|
850nm |
10 Lux |
|
|
940nm |
50 Lux |
|
| Gamma Correction |
0.45 |
|
| AGC |
+ 12 dB |
|
| ALC |
Electrical IRIS |
|
| Electrical Shutter |
1/60~1/100000 sec. |
|
| Lens Options |
4mm,6mm,8mm12mm,16mm |
|
| Power Supply Voltage DC |
DC 5V~12V |
|
| Power Supply Current |
Max 70mA |
|
| Storage temperature/humidity |
-20°C to +55°C / Max. 90%（No condensation） |
|
| Operating temperature/humidity |
-10°C to +45°C / Max.80%（No condensation） |
|
