CL-IR95OSDIR

  NEAR IR CCD CAMERA

                                 SPEC.

Model Name

CL-IR95OSDIR

Signal format

NTSC

Image Sensor

1/3inch IT CCD Sensor

Number of Pixel

811(H) X 508(V)

Scanning System

2 :1 Interlace

Synchronization

Internal

Horizontal Resolution

500 TVL

Video Out Level

1.0Vp-p, 75 ohm

Burst level

0.286 Vp-p

S/N ratio

56dB or better

Minimum Illumination

300nm~750nm

200000 Lux

850nm

0.5 Lux

940nm

20 Lux

Gamma Correction

0.45

ALC

Electrical IRIS

AGC

Selectable By OSD Manual

Shutter

Selectable By OSD Manual

Camera ID

Selectable By OSD Manual

IR LED

850nm IR LED*15PS(BUILD-IN)

Lens Options

4mm,6mm,8mm12mm,16mm

Power Supply Voltage DC

DC 11V to 15V

Power Supply Current

Max 230mA (at DC+12V)

Storage temperature/humidity

-20°C to +65°C / Max. 90%(No condensation)

Operating temperature/humidity

-10°C to +60°C / Max.80%(No condensation)
